A 1-section, solenoid-controlled hydraulic diverter valve designed for reliable flow switching in mobile hydraulic systems, featuring 90 L/min rated flow, 180 bar max pressure, and stable operation across -40°C to +80°C environments.
global shipping world wide
Online Service For 24 X 7
Support OEM customization
This 1-spool, sectional-structure valve enables fast, repeatable hydraulic flow diversion between circuits using electric solenoid actuation—ideal for remotely selecting functions (e.g., auxiliary attachments, implement circuits, tool change lines) on mobile equipment. Rated flow is 90 L/min (23.8 gpm) for high-demand auxiliaries, with 180 bar (2600 psi) maximum pressure capability for typical working hydraulics. It supports common hydraulic oil viscosity from 15 to 75 mm²/s (cSt), helping maintain consistent response across seasonal oil grades. The wide ambient range (-40°C to +80°C) suits both cold-start and high-heat job sites, supporting applications in material handling, construction/earth moving, agriculture, and industrial vehicles. Available for OEM/ODM manufacturing, private label, customization, wholesale supply, and distributor/agent cooperation for global markets.
| HSV09-DKL Series Flow Diverter Valve Parameters | |
|---|---|
| Control Method | Manual, Solenoid, Hydraulic, Electric |
| Spool | 1 Spool, 2 Spool, 3 Spool |
| Rated Flow | 90 L/min (23.8 US gpm) |
| Max Pressure | 250 bar (3600 psi) |
| Inlet Port | G1/2, G3/4 |
| Outlet Port | G1/2, G3/4 |
| Port Size | G1/2, G3/4 |
| Section | 1 Section, 2 Section, 3 Section |
| Structure Type | Sectional valve |
| Ambient Temperature Range | -20°C to +80°C (-4°F to +176°F) |
| Operating Viscosity Range | 15 - 75 mm²/s (15 cSt to 75 cSt) |
We provide OEM/ODM services. When your product orders reach a certain value, we can offer a variety of customization services, including labels, packaging, product colors, and more.
We support multiple currencies and diverse payment methods, such as T/T, L/C, Alibaba platform, China Manufacturing Payment Platform, bank transfer, and more.
We can provide samples, and the sample costs will be refunded to you in the form of deducted payments in the later stages.
