A 2-section, cable-operated monoblock directional control valve designed for mobile hydraulic systems, delivering 45 L/min flow capacity with up to 315 bar pressure rating and reliable operation across -40°C to +80°C environments.
global shipping world wide
Online Service For 24 X 7
Support OEM customization
Key features: 2-spool / 2-section configuration for controlling two hydraulic functions; cable actuation enables remote, flexible operator station layout and easier routing in compact machines; monoblock construction reduces potential leak paths and keeps installation compact. Performance: rated flow 45 L/min (11.8 US gpm); max pressure 315 bar (4600 psi); operating viscosity range 15–75 mm²/s (cSt) for compatibility with common hydraulic oils; ambient temperature range -40°C to +80°C for cold-start and high-heat duty. Typical applications: mobile equipment requiring reliable multi-function control such as telehandlers, forklifts, skid steers, mini/midi excavators, wheel loaders, backhoe loaders, dumpers, aerial platforms, and tractors with front-end loaders. Supply capabilities: factory direct manufacturing for global markets; available for wholesale, private label/branding, OEM/ODM, and customization; open to partnerships with distributors, wholesalers, agents, and trading companies.
| DM45 Series Monoblock Directional Valve Parameters | |
|---|---|
| Spool | 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool |
| Control Method | Manual, Pneumatic, Electro-pneumatic, Electro-hydraulic, Solenoid, Cable, Joystick |
| Port Size | G3/8, G1/2 |
| Section | 1 Section, 2 Section, 3 Section, 4 Section, 5 Section, 6 Section, 7 Section |
| Ambient Temperature Range | -40°C to +80°C (-40°F to +176°F) |
| Operating Viscosity Range | 15 - 75 mm²/s (15 cSt to 75 cSt) |
| Outlet Port | G1/2 |
| Max Pressure | 315 bar (4600 psi) |
| Rated Flow | 45 L/min (11.8 US gpm) |
| Structure Type | Monoblock valve |
We provide OEM/ODM services. When your product orders reach a certain value, we can offer a variety of customization services, including labels, packaging, product colors, and more.
We support multiple currencies and diverse payment methods, such as T/T, L/C, Alibaba platform, China Manufacturing Payment Platform, bank transfer, and more.
We can provide samples, and the sample costs will be refunded to you in the form of deducted payments in the later stages.
