2-spool electro-hydraulic monoblock directional valve with 40 L/min rated flow and 250 bar max pressure, designed for compact, reliable control of mobile hydraulic functions in harsh temperatures and varying oil viscosity conditions.
global shipping world wide
Online Service For 24 X 7
Support OEM customization
This electro-hydraulic monoblock directional valve integrates a compact one-piece body for reduced leakage paths and easy installation on mobile equipment. With 2 spools, it supports independent actuation of two hydraulic functions, ideal for attachments, auxiliary circuits, lifting/tilting, steering assist, and implement control. Performance highlights include 40 L/min (10.5 gpm) rated flow, 250 bar (3600 psi) maximum pressure capability, and stable operation across 15–75 cSt viscosity and -40°C to +80°C ambient temperatures—suited for outdoor, all-season machinery. Typical applications include material handling vehicles (forklifts, telehandlers), construction machines (skid steers, mini/midi excavators, loaders, dumpers), and agricultural equipment. Factory services support OEM/ODM, private label, customization, bulk supply, and distributor/agent partnerships for global markets.
| P40 Series Monoblock Directional Valve Parameters | |
|---|---|
| Control Method | Manual, Pneumatic, Electro-pneumatic, Electro-hydraulic, Solenoid, Hydraulic, Hydraulic and Manual, Cable, Joystick, Manual and Joystick |
| Spool | 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool |
| Rated Flow | 40 L/min (10.5 US gpm) |
| Max Pressure | 250 bar (3600 psi) |
| Inlet Port | G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Outlet Port | G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Port Size | G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Section | 1 Section, 2 Section, 3 Section, 4 Section, 5 Section, 6 Section, 7 Section |
| Structure Type | Monoblock valve |
| Ambient Temperature Range | -40°C to +80°C (-40°F to +176°F) |
| Operating Viscosity Range | 15 - 75 mm²/s (15 cSt to 75 cSt) |
We provide OEM/ODM services. When your product orders reach a certain value, we can offer a variety of customization services, including labels, packaging, product colors, and more.
We support multiple currencies and diverse payment methods, such as T/T, L/C, Alibaba platform, China Manufacturing Payment Platform, bank transfer, and more.
We can provide samples, and the sample costs will be refunded to you in the form of deducted payments in the later stages.
