3-section electro-hydraulic sectional control valve designed for mobile equipment, delivering up to 60 L/min flow and 350 bar pressure with wide temperature and viscosity tolerance and multiple port thread options for easy integration.
global shipping world wide
Online Service For 24 X 7
Support OEM customization
This 3-section electro-hydraulic sectional valve provides stable multi-function actuation for mobile hydraulic systems where compact installation, high pressure capability, and flexible plumbing are required. Rated flow is 60 L/min with max working pressure up to 350 bar, supporting demanding implements on construction, handling, and agricultural machines. It operates reliably across -40°C to +80°C ambient conditions and accommodates common hydraulic oil viscosity from 15 to 75 mm²/s, helping ensure consistent spool response in both cold starts and hot-duty cycles.
Integration is simplified with multiple inlet/outlet and working port options, including NPT, BSPP (G), metric (M), and SAE threads (e.g., 1/2 NPT, 3/4 NPT, G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, SAE 12). The sectional architecture allows configuration and service-friendly maintenance by replacing or tailoring sections as needed.
Available for OEM manufacturing, contract production, private label/branding, customization, and wholesale supply for global buyers; suitable for distributors, agents, importers, and trading companies seeking a high-pressure electro-hydraulic control solution.
| DCV60 Series Sectional Directional Valve Parameters | |
|---|---|
| Control Method | Manual, Pneumatic, Electro-pneumatic, Electro-hydraulic, Hydraulic, Hydraulic and Manual, Cable, Joystick, Solenoid and Manual, Solenoid and Joystick, Manual and Joystick |
| Spool | 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool, 8 Spool, 9 Spool, 10 Spool, 11 Spool, 12 Spool |
| Rated Flow | 60 L/min (15.8 US gpm) |
| Max Pressure | 350 bar (5100 psi) |
| Inlet Port | G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT |
| Outlet Port | G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT |
| Port Size | G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT |
| Section | 1 Section, 2 Section, 3 Section, 4 Section, 5 Section, 6 Section, 7 Section, 8 Section, 9 Section, 10 Section, 11 Section, 12 Section |
| Structure Type | Sectional valve |
| Ambient Temperature Range | -40°C to +80°C (-40°F to +176°F) |
| Operating Viscosity Range | 15 - 75 mm²/s (15 cSt to 75 cSt) |
